Gigabyte GA-EP45-UD3L

Specifications

CPU	1. Support for an Intel Core™ 2 Extreme processor/ Intel Core™ 2 Quad processor/Intel Core™ 2 Duo processor/Intel Pentium Dual-Core processor/Intel Celeron processor in the LGA 775 package (Refer to CPU support list for more information) 2. L2 cache varies with CPU
Front Side Bus	1. 1600/1333/1066/800 MHz FSB
Chipset	1. North Bridge: Intel P45 Express Chipset 2. South Bridge: Intel ICH10
Memory	1. 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory 2. Dual channel memory architecture 3. Support for DDR2 1366+/1066/800/667 MHz memory modules Refer to Memory Support List for more information.
Audio	1. Realtek ALC888 codec 2. High Definition Audio 3. 2/4/5.1/7.1-channel 4. Support for S/PDIF In/Out 5. Support for CD In
LAN	1. 1 x Realtek 8111C chips (10/100/1000 Mbit)
Expansion Slots	1. 1 x PCI Express x16 slot, running at x16 (The PCI Express x16 slot conforms to PCI Express 2.0 standard) 2. 4 x PCI Express x1 slot 3. 2 x PCI slots
Storage Interface	South Bridge: 1. 6x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3, SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices GIGABYTE SATA2 (JMicron 368) chip: 1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices iTE IT8718 chip: 1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	1. Integrated in the South Bridge 2. Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1. 1 x 24-pin ATX main power connector 2. 1 x 4-pin ATX 12V power connector 3. 1 x floppy disk drive connector 4. 1 x IDE connector 5. 6 x SATA 3Gb/s connectors 6. 1 x CPU fan header 7. 2 x system fan headers 8. 1 x power fan header 9. 1 x front panel header 10. 1 x front panel audio header 11. 1 x CD In connector 12. 1 x S/PDIF In header 13. 1 x S/PDIF Out header 14. 2 x USB 2.0/1.1 headers 15. 1 x parallel port header 16. 1 x serial port header 17. 1 x power LED header 18. 1 x chassis intrusion header
Back Panel Connectors	1. 1 x PS/2 mouse port 2. 1 x PS/2 keyboard/mouse port 3. 1 x optical S/PDIF Out connector 4. 1 x coaxial S/PDIF Out connector 5. 8 x USB 2.0/1.1 ports 6. 1 x RJ-45 ports 7. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line
I/O Controller	1. iTE IT8718 chip
H/W Monitoring	1. System voltage detection 2. CPU/System temperature detection 3. CPU/System/Power fan speed detection 4. CPU overheating warning 5. CPU/System/Power fan fail warning 6. CPU/System fan speed control
BIOS	1. 2 x 8 Mbit flash 2. Use of licensed AWARD BIOS 3. Support for Dual BIOS 4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	1. Support for @BIOS 2. Support for Q-Flash 3. Support for Dual BIOS 4. Support for Download Center 5. Support for Xpress Install 6. Support for Xpress Recovery2 7. Support for EasyTune 6 8. Support for Dynamic Energy Saver Advanced 9. Support for Time Repair 10. Support for Q-Share
Bundle Software	1. Norton Internet Security (OEM version)
Operating System	1. Support for Microsoft/ Windows/ Vista/XP
Form Factor	1. ATX Form Factor; 30.5cm x 21.0cm

Gigabyte GA-EP45-UD3L

Giá: 2,078,070 VND

Gigabyte GA-EP45-UD3LR

Intel^® P45 + ICH10R Chipset

Revolution energy saving design with DES Advanced featuring hardware based Dynamic 4-Gear switching
Supports 45nm Intel Core 2 multi-core processors with FSB 1600 MHz
Dual channel DDR2 1366+ for remarkable system performance
Ultimate graphics performance with PCI-E x16 interface
Features high speed Gigabit Ethernet connection
Features SATA 3Gb/s with RAID function
Patented DualBIOS with dual hardware BIOS protection
Home theater quality 8-channel High Definition Audio

Specifications

CPU	Support for an Intel Core™ 2 Extreme processor/ Intel Core™ 2 Quad processor/Intel Core™ 2 Duo processor/Intel Pentium Dual-Core processor/Intel Celeron processor in the LGA 775 package (Refer to CPU support list for more information) L2 cache varies with CPU
Front Side Bus	1600/1333/1066/800 MHz FSB
Chipset	North Bridge: Intel P45 Express Chipset South Bridge: Intel ICH10R
Memory	4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory Dual channel memory architecture Support for DDR2 1366+/1066/800/667 MHz memory modules Refer to Memory Support List for more information.
Audio	Realtek ALC888 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF In/Out Support for CD In
LAN	1 x Realtek 8111C chips (10/100/1000 Mbit)
Expansion Slots	1 x PCI Express x16 slot, running at x16 (The PCI Express x16 slot conforms to PCI Express 2.0 standard) 4 x PCI Express x1 slot 2 x PCI slots
Storage Interface	South Bridge: 6x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3, SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10 GIGABYTE SATA2 (JMicron 368) chip: 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices iTE IT8718 chip: 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	Integrated in the South Bridge Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x floppy disk drive connector 1 x IDE connector 6 x SATA 3Gb/s connectors 1 x CPU fan header 2 x system fan headers 1 x power fan header 1 x front panel header 1 x front panel audio header 1 x CD In connector 1 x S/PDIF In header 1 x S/PDIF Out header 2 x USB 2.0/1.1 headers 1 x parallel port header 1 x serial port header 1 x power LED header 1 x chassis intrusion header
Back Panel Connectors	1 x PS/2 mouse port 1 x PS/2 keyboard/mouse port 1 x optical S/PDIF Out connector 1 x coaxial S/PDIF Out connector 8 x USB 2.0/1.1 ports 1 x RJ-45 ports 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line
I/O Controller	iTE IT8718 chip
H/W Monitoring	System voltage detection CPU/System temperature detection CPU/System/Power fan speed detection CPU overheating warning CPU/System/Power fan fail warning CPU/System fan speed control
BIOS	2 x 8 Mbit flash Use of licensed AWARD BIOS Support for Dual BIOS PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	Support for @BIOS Support for Q-Flash Support for Dual BIOS Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune 6 Support for Dynamic Energy Saver Advanced Support for Time Repair Support for Q-Share
Bundle Software	Norton Internet Security (OEM version)
Operating System	Support for Microsoft/ Windows/ Vista/XP
Form Factor	ATX Form Factor; 30.5cm x 21.0cm

Gigabyte GA-EP45-UD3LR

Giá: 2,170,020 VND

Gigabyte GA-EQ45M-S2

Specifications

CPU	1. Support for an Intel^® Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel^® Core™ 2 Duo processor/Intel^® Pentium^® Dual-Core processo/Intel^® Celeron^® processor in the LGA 775 package 2. L2 cache varies with CPU
Front Side Bus	1. 1333/1066/800 MHz FSB
Chipset	1. North Bridge: Intel^® Q45 Chipset 2. South Bridge: Intel^® ICH10DO
Memory	1. 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory (Note 1) (Note 2) 2. Dual channel memory architecture 3. Support for DDR2 800/667 MHz memory modules (Go to GIGABYTE's website for the latest memory support list.)
Onboard Graphics	North Bridge: 1. 1 x D-Sub port 2. 1 x DVI-D port (Note 3) (Note 4)
Audio	1. Realtek ALC888 codec 2. High Definition Audio 3. 2/4/5.1/7.1-channel 4. Support for S/PDIF In/Out 5. Support for CD In
LAN	1. Intel 82567LM chip (10/100/1000 Mbit)
Expansion Slots	1. 1 x PCI Express x16 slot, running at x16 (Go to GIGABYTE's website for the graphics card support list.) 2. 1 x PCI Express x1 slot 3. 2 x PCI slots
Storage Interface	South Bridge: 1. 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices 2. Support for SATA RAID 0, RAID 1, RAID 5 and RAID 10. JMicron 368 chip: 1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices iTE IT8720 chip: 1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	1. Integrated in the south bridge 2. Up to 12 USB 2.0/1.1 ports (6 on the back panel, 6 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1. 1 x 24-pin ATX main power connector 2. 1 x 8-pin ATX 12V power connector 3. 1 x floppy disk drive connector 4. 1 x IDE connector 5. 6 x SATA 3Gb/s connectors 6. 1 x CPU fan header 7. 1 x system fan header 8. 1 x front panel header 9. 1 x front panel audio header 10. 1 x CD In connector 11. 1 x S/PDIF In/Out header 12. 3 x USB 2.0/1.1 headers 13. 1 x serial port header 14. 1 x debug card header (Note 5) 15. 1 x jumper for enabling Intel Management Engine Feature 16. 1 x clearing CMOS jumper 17. 1 x power LED header 18. 1 x chassis intrusion header
Back Panel Connectors	1. 1 x PS/2 keyboard port 2. 1 x PS/2 mouse port 3. 1 x parallel port 4. 1 x D-Sub port 5. 1 x DVI-D port (Note 3) (Note 4) 6. 6 x USB 2.0/1.1 ports 7. 1 x RJ-45 port 8. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line out/Microphone)
I/O Controller	1. iTE IT8720 chip
H/W Monitoring	1. System voltage detection 2. CPU/System temperature detection 3. CPU/System fan speed detection 4. CPU overheating warning 5. CPU/System fan fail warning 6. CPU/System fan speed control (Note 6)
BIOS	1. 2 x 16 Mbit flash 2. Use of licensed AWARD BIOS 3. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	1. Support for @BIOS 2. Support for Q-Flash 3. Support for Virtual Dual BIOS 4. Support for Download Center 5. Support for Xpress Install 6. Support for Xpress Recovery2 7. Support for Dynamic Energy Saver Advanced 8. Support for Ultra TPM 9. Support for Time Repair 10. Support for Q-Share
Bundle Software	1. Norton Internet Security (OEM version)
Operating System	1. Support for Microsoft^® Windows Vista/XP
Form Factor	1. Micro ATX Form Factor; 24.4cm x 24.4cm

Gigabyte GA-EQ45M-S2

Giá: 2,096,460 VND

Gigabyte GA-EP45-UD3R

Intel^® P45 + ICH10R Chipset

Ultra Durable 3 technology with 2 oz copper PCB for 50°C cooler working temperature

Revolution energy saving design with DES Advanced featuring hardware based Dynamic 6-Gear switching
Supports 45nm Intel^® Core 2™ multi-core processors with FSB 1600 MHz
Natively support to dual channel DDR2 1366+* for remarkable system performance
Ultimate graphics performance with PCI-E x16 interface
100% 50,000 hour lifespan Japanese solid capacitors design
DualBIOS solution gives a multiple security to the system
Hardware Overvoltage Control IC Provides more voltage control options on CPU, North bridge and memory
Blu-ray playback outputs supported by high quality 106dB SNR ALC889A HD audio

Specifications

CPU	Support for an Intel Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel Core™ 2 Duo processor/ Intel^® Pentium^® processor Extreme Edition/Intel^® Pentium^® D processor/ Intel^® Pentium^® 4 processor Extreme Edition/Intel^® Pentium^® 4 processor/ Intel^® Celeron^® processor in the LGA 775 package (Refer to CPU support list for more information) L2 cache varies with CPU
Front Side Bus	1600/1333/1066/800 MHz FSB
Chipset	North Bridge: Intel P45 Express Chipset South Bridge: Intel ICH10R
Memory	4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory Dual channel memory architecture Support for DDR2 1366+/1066/800/667 MHz memory modules Refer to Memory Support List for more information.
Audio	Realtek ALC889A codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF In/Out Support for CD In
LAN	1 x Realtek 8111C chips (10/100/1000 Mbit)
Expansion Slots	1 x PCI Express x16 slot, running at x16 (The PCI Express x16 slot conforms to PCI Express 2.0 standard) 3 x PCI Express x1 slot 3 x PCI slots
Storage Interface	South Bridge: 6x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3, SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10 GIGABYTE SATA2 chip: 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices 2 x SATA 3Gb/s connectors (GSATA2_0, GSATA2_1) supporting up to 2 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1 and JBOD iTE IT8718 chip: 1 x floppy disk drive connector supporting up to 1 floppy disk drive
IEEE 1394a	T.I. TSB43AB23 chip Up to 3 IEEE 1394a ports (2 on the back panel, 1 via the IEEE 1394a bracket connected to the internal IEEE 1394a header)
USB	Integrated in the South Bridge Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x floppy disk drive connector 1 x IDE connector 8 x SATA 3Gb/s connectors 1 x CPU fan header 2 x system fan headers 1 x power fan header 1 x front panel header 1 x front panel audio header 1 x CD In connector 1 x S/PDIF In header 1 x S/PDIF Out header 2 x USB 2.0/1.1 headers 1 x IEEE 1394a header 1 x parallel port header 1 x serial port header 1 x power LED header 1 x chassis intrusion header
Back Panel Connectors	1 x PS/2 mouse port 1 x PS/2 keyboard/mouse port 1 x optical S/PDIF Out connector 1 x coaxial S/PDIF Out connector 8 x USB 2.0/1.1 ports 2 x IEEE 1394a ports 1 x RJ-45 ports 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line
I/O Controller	iTE IT8718 chip
H/W Monitoring	System voltage detection CPU/System temperature detection CPU/System/Power fan speed detection CPU overheating warning CPU/System/Power fan fail warning CPU/System fan speed control
BIOS	2 x 8 Mbit flash Use of licensed AWARD BIOS Support for Dual BIOS PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	Support for @BIOS Support for Q-Flash Support for Dual BIOS Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune 6 Support for Dynamic Energy Saver Advanced Support for Time Repair Support for Q-Share
Bundle Software	Norton Internet Security (OEM version)
Operating System	Support for Microsoft/ Windows/ Vista/XP
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Remark	Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.

Gigabyte GA-EP45-UD3R

Giá: 2,427,480 VND

Gigabyte GA-EP45-UD3P

Intel^® P45 + ICH10R Chipset

Ultra Durable 3 technology with 2 oz copper PCB for 50°C cooler working temperature
Revolution energy saving design with DES Advanced featuring hardware based Dynamic 6-Gear switching
Supports 45nm Intel^® Core 2™ multi-core processors with FSB 1600 MHz
Natively support to dual channel DDR2 1366+* for remarkable system performance
2 PCI-E 2.0 x16 graphic interface with CrossFireX support for ultimate graphics performance
Built-in TPM chip with 2048bits encryption to highest level digital data protection
2 Gigabit Ethernet LAN with Teaming functionality
100% 50,000 hour lifespan Japanese solid capacitors design
DualBIOS solution gives a multiple security to the system
Hardware Overvoltage Control IC Provides more voltage control options on CPU, North bridge and memory
Supports Dolby Home Theater^® audio to create a stunning surround sound listening experience.
Blu-ray playback outputs supported by high quality 106dB SNR ALC889A HD audio

Specifications

CPU	Support for an Intel Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel Core™ 2 Duo processor/ Intel^® Pentium^® processor Extreme Edition/Intel^® Pentium^® D processor/ Intel^® Pentium^® 4 processor Extreme Edition/Intel^® Pentium^® 4 processor/ Intel^® Celeron^® processor in the LGA 775 package (Refer to CPU support list for more information) L2 cache varies with CPU
Front Side Bus	1600/1333/1066/800 MHz FSB
Chipset	North Bridge: Intel^® P45 Express Chipset South Bridge: Intel^® ICH10R
Memory	4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory Dual channel memory architecture Support for DDR2 1366+/1066/800/667 MHz memory modules Refer to Memory Support List for more information.
Audio	Realtek ALC889A codec High Definition Audio 2/4/5.1/7.1-channel Support for Dolby Home Theater Support for S/PDIF In/Out Support for CD In
LAN	2 x Realtek 8111C chips (10/100/1000 Mbit) Support for Teaming
Expansion Slots	1 x PCI Express x16 slot, running at x16 1 x PCI Express x16 slot, running at x8 (The PCIEx16 and PCIEx8 slots support ATI CrossFireX technology and conform to PCI Express 2.0 standard.) 3 x PCI Express x1 slot 2 x PCI slots
Storage Interface	South Bridge: 6x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3, SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10 GIGABYTE SATA2 chip: 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices 2 x SATA 3Gb/s connectors (GSATA2_0, GSATA2_1) supporting up to 2 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1 and JBOD iTE IT8718 chip: 1 x floppy disk drive connector supporting up to 1 floppy disk drive
IEEE 1394a	T.I. TSB43AB23 chip Up to 3 IEEE 1394a ports (2 on the back panel, 1 via the IEEE 1394a bracket connected to the internal IEEE 1394a header)
USB	Integrated in the South Bridge Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x floppy disk drive connector 1 x IDE connector 8 x SATA 3Gb/s connectors 1 x CPU fan header 2 x system fan headers 1 x power fan header 1 x front panel header 1 x front panel audio header 1 x CD In connector 1 x S/PDIF In header 1 x S/PDIF Out header 2 x USB 2.0/1.1 headers 1 x IEEE 1394a header 1 x parallel port header 1 x serial port header 1 x power LED header 1 x chassis intrusion header
Back Panel Connectors	1 x PS/2 mouse port 1 x PS/2 keyboard/mouse port 1 x optical S/PDIF Out connector 1 x coaxial S/PDIF Out connector 8 x USB 2.0/1.1 ports 2 x IEEE 1394a ports 2 x RJ-45 ports 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line
I/O Controller	iTE IT8718 chip
H/W Monitoring	System voltage detection CPU/System temperature detection CPU/System/Power fan speed detection CPU overheating warning CPU/System/Power fan fail warning CPU/System fan speed control
BIOS	2 x 8 Mbit flash Use of licensed AWARD BIOS Support for Dual BIOS PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	Support for @BIOS Support for Q-Flash Support for Dual BIOS Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune 6 Support for Dynamic Energy Saver Advanced Support for Time Repair Support for Q-Share
Bundle Software	Norton Internet Security (OEM version)
Operating System	Support for Microsoft/ Windows/ Vista/XP
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Remark	Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.

Gigabyte GA-EP45-UD3P

Giá: 2,666,550 VND

Gigabyte GA-EP45T-UD3LR Mua kèm Ram DDR3 Tặng nón BH

Intel^® P45 + ICH10R Chipset

Revolution energy saving design with DES Advanced featuring hardware based Dynamic 4-Gear switching
Supports 45nm Intel Core 2 multi-core processors with FSB 1600 MHz
Natively support dual channel DDR3 2200+ for remarkable system performance
Ultimate graphics performance with PCI-E x16 interface
Features high speed Gigabit Ethernet connection
Features SATA 3Gb/s with RAID function
Patented DualBIOS with dual hardware BIOS protection
Home theater quality 8-channel High Definition Audio

Specifications

CPU	Support for an Intel Core™ 2 Extreme processor/ Intel Core™ 2 Quad processor/Intel Core™ 2 Duo processor/Intel Pentium Dual-Core processor/Intel Celeron processor in the LGA 775 package (Refer to CPU support list for more information) L2 cache varies with CPU
Front Side Bus	1600/1333/1066/800 MHz FSB
Chipset	North Bridge: Intel P45 Express Chipset South Bridge: Intel ICH10R
Memory	4 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory Dual channel memory architecture Support for DDR3 2200+/1333/1066/800 MHz memory modules * Refer to Memory Support List for more information.
Audio	Realtek ALC888 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF In/Out Support for CD In
LAN	1 x Realtek 8111C chips (10/100/1000 Mbit)
Expansion Slots	1 x PCI Express x16 slot, running at x16 (The PCI Express x16 slot conforms to PCI Express 2.0 standard) 4 x PCI Express x1 slot 2 x PCI slots
Storage Interface	South Bridge: 6x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3, SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10 GIGABYTE SATA2 (JMicron 368) chip: 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices iTE IT8718 chip: 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	Integrated in the South Bridge Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x floppy disk drive connector 1 x IDE connector 6 x SATA 3Gb/s connectors 1 x CPU fan header 2 x system fan headers 1 x power fan header 1 x front panel header 1 x front panel audio header 1 x CD In connector 1 x S/PDIF In header 1 x S/PDIF Out header 2 x USB 2.0/1.1 headers 1 x parallel port header 1 x serial port header 1 x power LED header 1 x chassis intrusion header
Back Panel Connectors	1 x PS/2 mouse port 1 x PS/2 keyboard/mouse port 1 x optical S/PDIF Out connector 1 x coaxial S/PDIF Out connector 8 x USB 2.0/1.1 ports 1 x RJ-45 ports 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line
I/O Controller	iTE IT8718 chip
H/W Monitoring	System voltage detection CPU/System temperature detection CPU/System/Power fan speed detection CPU overheating warning CPU/System/Power fan fail warning CPU/System fan speed control
BIOS	2 x 8 Mbit flash Use of licensed AWARD BIOS Support for Dual BIOS PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	Support for @BIOS Support for Q-Flash Support for Dual BIOS Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune 6 Support for Dynamic Energy Saver Advanced Support for Time Repair Support for Q-Share
Bundle Software	Norton Internet Security (OEM version)
Operating System	Support for Microsoft/ Windows/ Vista/XP
Form Factor	ATX Form Factor; 30.5cm x 21.0cm

Gigabyte GA-EP45T-UD3LR (Mua kèm Ram DDR3 Tặng nón BH)

Giá: 2,556,210 VND

GIGABYTE GA-EG45M-DS2H

Intel^®G45 + ICH10R Chipset

Specifications

CPU	Support for an Intel^® Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel^® Core™ 2 Duo processor/ Intel^® Pentium^® Dual-Core processor/Intel^® Celeron^® processor in the LGA 775 package (Go to CPU support list for the latest CPU support list.) L2 cache varies with CPU
Front Side Bus	1600 (O.C.)/1333/1066/800 MHz FSB
Chipset	North Bridge: Intel^® G45 Chipset South Bridge: Intel^® ICH10R
Memory	4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory Dual channel memory architecture Support for DDR2 1066(O.C.)/800/667 MHz memory modules (Go to GIGABYTE's website for the latest memory support list.)
Onboard Graphics	Integrated in the North Bridge
Audio	Realtek ALC889A codec High Definition Audio 2/4/5.1/7.1-channel Support for Dolby^® Home Theater Support for S/PDIF In/Out Support for CD In
LAN	Realtek 8111C chip (10/100/1000 Mbit)
Expansion Slots	1 x PCI Express x4 slot (Refer to the VGA device support list.) 1 x PCI Express x1 slot 2 x PCI slots
Storage Interface	South Bridge: 5 x SATA 3Gb/s connectors supporting up to 5 SATA 3Gb/s devices 1 x eSATA 3Gb/s port on the back panel supporting up to 1 SATA 3Gb/s device Support for SATA RAID 0, RAID 1, RAID 5 and RAID 10 iTE IT8213 chip: 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices iTE IT8718 chip: 1 x floppy disk drive connector supporting up to 1 floppy disk drive
IEEE 1394	T.I. TSB43AB23 chip Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394 bracket connected to the internal IEEE 1394 header)
USB	Integrated in the South Bridge Up to 12 USB 2.0/1.1 ports (6 on the back panel, 6 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x floppy disk drive connector 1 x IDE connector 5 x SATA 3Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x CD In connector 1 x S/PDIF In header 1 x S/PDIF Out header 3 x USB 2.0/1.1 headers 1 x IEEE 1394a header 1 x parallel port header 1 x serial port header 1 x power LED header 1 x chassis intrusion header
Back Panel Connectors	1 x PS/2 keyboard or PS/2 mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 1 x optical S/PDIF Out connector 1 x eSATA 3Gb/s port 1 x IEEE 1394a port 6 x USB 2.0/1.1 ports 1 x RJ-45 port 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line out/Microphone)
I/O Controller	iTE IT8718 chip
H/W Monitoring	System voltage detection CPU/System temperature detection CPU/System fan speed detection CPU overheating warning CPU/System fan fail warning CPU fan speed control
BIOS	2 x 8 Mbit flash Use of licensed AWARD BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	Support for @BIOS Support for Q-Flash Support for Virtual Dual BIOS Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune Support for Dynamic Energy Saver Advanced Support for Ultra TPM Support for Time Repair Support for Q-Share
Bundle Software	Norton Internet Security (OEM version)
Operating System	Support for Microsoft^® Windows^® Vista/XP
Form Factor	Micro ATX Form Factor; 24.4cm x 24.4cm
Note	After creating the password(s) and key(s) associated the TPM, be sure to store them in a secure location and back them up. Loss of the password(s) or the key(s) will render the files encrypted via the TPM unable to be cracked or read. Though the TPM delivers the latest data security technology, it does not guarantee data integrity or give hardware protection. GIGABYTE is not liable for loss of encrypted data as a result of hardware damage. (Note1)If you want to uninstall the Ultra TPM utility, be sure to insert the USB flash drive containing the TPM key into your computer before the uninstallation. (Note2) Ultra TPM feature is optional due to different regional policy.
Remark	Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.

Revolution energy saving design with DES advanced technology featuring hardware based Dynamic 4-Gear switching.
Supports 45nm Intel^® Core™ 2 multi-core processors with FSB 1600 by O.C. MHz
Dual channel DDR2 1066 by O.C. for remarkable system performance
Integrated Intel Graphics Media Accelerator X4500HD (Intel GMA X4500HD)
Built-in TPM chip with 2048bits encryption to highest level digital data protection.
(Ultra TPM feature is optional due to different regional policy.)
Features high speed Gigabit Ethernet and IEEE1394 connection
High quality 106dB SNR ALC889A HD audio.
Supports Dolby Home Theater^® audio to create a stunning surround sound listening experience
Chipset built-in hardware video decode acceleration for smoother HD video playback and Blu-ray/ HD DVD support
Integrated HDMI interface for high Definition video (1080) playback with HDCP support

GIGABYTE GA-EG45M-DS2H

Giá: call VND

GA-EG45M-UD2H

Specifications

CPU

1.       Support for an Intel^® Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel^® Core™ 2 Duo processor/Intel^® Pentium^® Dual-Core processo/Intel^® Celeron^® processor in the LGA 775 package
(Go to GIGABYTE's website for the latest CPU support list.)

2.       L2 cache varies with CPU

Front Side Bus

1.       1600(O.C.)/1333/1066/800 MHz FSB

Chipset

1.       North Bridge: Intel^® G45 Chipset

2.       South Bridge: Intel^® ICH10R

Memory

1.       4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory

2.       Dual channel memory architecture

3.       Support for DDR2 1066(O.C.)/800/667 MHz memory modules

(Go to GIGABYTE's website for the latest memory support list.)

Onboard Graphics

North Bridge:

1.       1 x D-Sub port

2.       1 x DVI-D port (Note 1)

3.       1 x HDMI port (Note 2)

Audio

1.       Realtek ALC889A codec

2.       High Definition Audio

3.       2/4/5.1/7.1-channel

4.       Support for Dolby^® Home Theater

5.       Support for S/PDIF In/Out

6.       Support for CD In

LAN

1.       Realtek 8111DL chip (10/100/1000 Mbit)

Expansion Slots

1.       1 x PCI Express x16 slot, running at x16 (PCIEX16)
(The PCI Express x16 slot conforms to PCI Express 2.0 standard.)

2.       1 x PCI Express x1 slot

3.       2 x PCI slots

Storage Interface

South Bridge:

1.       5 x SATA 3Gb/s connectors supporting up to 5 SATA 3Gb/s devices

2.       1 x eSATA 3Gb/s port on the back panel supporting up to 1 SATA 3Gb/s device

3.       Support for SATA RAID 0, RAID 1, RAID 5 and RAID 10

JMicron 368 chip:

1.       1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices

iTE IT8718 chip:

1.       1 x floppy disk drive connector supporting up to 1 floppy disk drive

IEEE 1394

1.       T.I. TSB43AB23 chip

2.       Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394 bracket connected to the internal IEEE 1394 header)

USB

1.       Integrated in the South Bridge

2.       Up to 12 USB 2.0/1.1 ports (6 on the back panel, 6 via the USB brackets connected to the internal USB headers)

Internal I/O Connectors

1.       1 x 24-pin ATX main power connector

2.       1 x 4-pin ATX 12V power connector

3.       1 x floppy disk drive connector

4.       1 x IDE connector

5.       5 x SATA 3Gb/s connectors

6.       1 x CPU fan header

7.       1 x system fan header

8.       1 x front panel header

9.       1 x front panel audio header

10.    1 x CD In connector

11.    1 x S/PDIF In header

12.    1 x S/PDIF Out header

13.    3 x USB 2.0/1.1 headers

14.    1 x IEEE 1394a header

15.    1 x parallel port header

16.    1 x serial port header

17.    1 x power LED header

18.    1 x chassis intrusion header

Back Panel Connectors

1.       1 x PS/2 keyboard or PS/2 mouse port

2.       1 x D-Sub port

3.       1 x DVI-D port

4.       1 x HDMI port

5.       1 x optical S/PDIF Out connector

6.       1 x eSATA 3Gb/s port

7.       1 x IEEE 1394a port

8.       6 x USB 2.0/1.1 ports

9.       1 x RJ-45 port

10.    6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line out/Microphone)

I/O Controller

1.       iTE IT8718 chip

H/W Monitoring

1.       System voltage detection

2.       CPU/System temperature detection

3.       CPU/System fan speed detection

4.       CPU overheating warning

5.       CPU/System fan fail warning

6.       CPU fan speed control

BIOS

1.       2 x 8 Mbit flash

2.       Use of licensed AWARD BIOS

3.       Support for DualBIOS™

4.       PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features

1.       Support for @BIOS

2.       Support for Q-Flash

3.       Support for Virtual Dual BIOS

4.       Support for Download Center

5.       Support for Xpress Install

6.       Support for Xpress Recovery2

7.       Support for EasyTune

8.       Support for Dynamic Energy Saver Advanced

9.       Support for Time Repair

10.    Support for Q-Share

Bundle Software

1.       Norton Internet Security (OEM version)

Operating System

1.       Support for Microsoft^® Windows^® Vista/XP

Form Factor

1.       Micro ATX Form Factor; 24.4cm x 24.4cm

Note

(Note 1)The DVI-D port does not support D-Sub connection by adapter.
(Note 2)The PCI Express x16 slot share the PCI Express x16 bus with the HDMI and the DVI-D ports.When the PCI Express x16 slot is in use, the HDMI and the DVI-D ports become unavailable.

Remark

1.       Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.

2.       Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.

GA-EG45M-UD2H

Giá: 2,592,990 VND

GA-P43-ES3G

Specifications

CPU	1. Support for an Intel^® Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel^® Core™ 2 Duo processor/Intel^® Pentium^® processor Extreme Edition/Intel^® Pentium^® D processor/Intel^® Pentium^® 4 processor Extreme Edition/Intel^® Pentium^® 4 processor/Intel^® Celeron^® processor in the LGA 775 package (Go to GIGABYTE's website for the latest CPU support list.) 2. L2 cache varies with CPU
Front Side Bus	1. 1600(O.C.)/1333/1066/800 MHz FSB
Chipset	1. North Bridge: Intel^® P43 Express Chipset 2. South Bridge: Intel^® ICH10
Memory	1. 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory 2. Dual channel memory architecture 3. Support for DDR2 1200/1066/800/667 MHz 4. memory modules (Go to GIGABYTE's website for the latest memory support list.)
Audio	1. Realtek ALC888 codec 2. High Definition Audio 3. 2/4/5.1/7.1-channel 4. Support for S/PDIF Out 5. Support for CD In
LAN	1. Realtek 8111C chip (10/100/1000 Mbit)
Expansion Slots	1. 1 x PCI Express x16 slot 2. 1 x PCI Express x1 slot 3. 5 x PCI slots
Storage Interface	South Bridge: 1. 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices JMicron 368 chip: 1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices iTE IT8718 chip: 1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	1. Integrated in the South Bridge 2. Up to 12 USB 2.0/1.1 ports (6 on the back panel, 6 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1. 1 x 24-pin ATX main power connector 2. 1 x 4-pin ATX 12V power connector 3. 1 x floppy disk drive connector 4. 1 x IDE connector 5. 6 x SATA 3Gb/s connectors 6. 1 x CPU fan header 7. 2 x system fan headers 8. 1 x front panel header 9. 1 x front panel audio header 10. 1 x CD In connector 11. 1 x S/PDIF Out header 12. 3 x USB 2.0/1.1 headers 13. 1 x power LED header 14. 1 x chassis intrusion header
Back Panel Connectors	1. 1 x PS/2 keyboard port 2. 1 x PS/2 mouse port 3. 1 x parallel port 4. 1 x serial port 5. 1 x coaxial S/PDIF Out connector 6. 6 x USB 2.0/1.1 ports 7. 1 x RJ-45 ports 8. 3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller	1. iTE IT8718 chip
H/W Monitoring	1. System voltage detection 2. CPU/System temperature detection 3. CPU/System fan speed detection 4. CPU overheating warning 5. CPU/System fan fail warning 6. CPU/System samrt fan control
BIOS	1. 2 x 8 Mbit flash 2. Use of licensed AWARD BIOS 3. Support for DualBIOS™ 4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	1. Support for @BIOS 2. Support for Download Center 3. Support for Q-Flash 4. Support for EasyTune 5. Support for Xpress Install 6. Support for Xpress Recovery2 7. Support for Virtual Dual BIOS 8. Support for Easy Energy Saver
Bundle Software	1. Norton Internet Security (OEM version)
Operating System	1. Support for Microsoft^® Windows Vista/XP
Form Factor	1. ATX Form Factor; 30.5cm x 21cm
Remark	1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. 2. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.

GA-P43-ES3G

Giá: 1,581,540 VND

Gigabyte GA-EP43-S3L

Intel^® P43 + ICH10 Chipset

Revolution energy saving design with DES technology featuring hardware based Dynamic 4-Gear switching
Supports 45nm Intel^® Core™ 2 multi-core processors with FSB 1600 (O.C.) MHz
Dual channel DDR2 1200+ for remarkable system performance
Ultimate graphics performance with PCI-E x16 2.0 interface
Integrated high speed SATA 3Gb/s
Features high speed Gigabit Ethernet connection
8 channel High definition audio

Specifications

CPU	Support for an Intel^® Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel^® Core™ 2 Duo processor/ Intel® Pentium^® Dual-Core processor/Intel^® Celeron^® processor in the LGA 775 package (Note) This motherboard is designed with VRD11.1 power phase, and cannot be compatible with VRD10 designed CPU. Please refer to 'CPU Support List' for details. L2 cache varies with CPU
Front Side Bus	1600(O.C.)/1333/1066/800 MHz FSB
Chipset	North Bridge: Intel^® P43 Express Chipset South Bridge: Intel^® ICH10
Memory	4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory Dual channel memory architecture Support for DDR2 1200+/1066/800/667 MHz memory modules (Go to GIGABYTE's website for the latest memory support list.)
Audio	Realtek ALC888 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF In/Out Support for CD In
LAN	Realtek 8111C chip (10/100/1000 Mbit)
Expansion Slots	1 x PCI Express x16 slot (The PCI Express x16 slot conforms to PCI Express 2.0 standard.) 4 x PCI Express x1 slots 2 x PCI slots
Storage Interface	South Bridge: 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices JMicron 368 chip: 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices iTE IT8718 chip: 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	Integrated in the South Bridge Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x floppy disk drive connector 1 x IDE connector 6 x SATA 3Gb/s connectors 1 x CPU fan header 2 x system fan headers 1 x power fan header 1 x front panel header 1 x front panel audio header 1 x CD In connector 1 x S/PDIF In header 1 x S/PDIF Out header 2 x USB 2.0/1.1 headers 1 x parallel port header 1 x serial port header 1 x power LED header 1 x chassis intrusion header
Back Panel Connectors	1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x coaxial S/PDIF Out connector 8 x USB 2.0/1.1 ports 1 x RJ-45 ports 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller	iTE IT8718 chip
H/W Monitoring	System voltage detection CPU/System temperature detection CPU/System/Power fan speed detection CPU overheating warning CPU/System/Power fan fail warning CPU/System fan speed control
BIOS	2 x 8 Mbit flash Use of licensed AWARD BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	Support for @BIOS Support for Q-Flash Support for Virtual Dual BIOS Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune Support for Dynamic Energy Saver Advanced Support for Time Repair Support for Q-Share
Bundle Software	Norton Internet Security (OEM version)
Operating System	Support for Microsoft^® Windows^® Vista/XP
Form Factor	ATX Form Factor; 30.5cm x 21.0cm
Remark	Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.

Gigabyte GA-EP43-S3L

Giá: 1,729,000 VND

Gigabyte GA-EP43-US3L

Specifications

CPU	1. Support for an Intel^® Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel^® Core™ 2 Duo processor/ Intel^® Pentium^® Dual-Core processor/Intel^® Celeron^® processor in the LGA 775 package (Go to GIGABYTE's website for the latest CPU support list.) 2. L2 cache varies with CPU
Front Side Bus	1. 1600(O.C.)/1333/1066/800 MHz FSB
Chipset	1. North Bridge: Intel^® P43 Express Chipset 2. South Bridge: Intel^® ICH10
Memory	1. 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory 2. Dual channel memory architecture 3. Support for DDR2 1200+/1066/800/667 MHz memory modules (Go to GIGABYTE's website for the latest memory support list.)
Audio	1. Realtek ALC888 codec 2. High Definition Audio 3. 2/4/5.1/7.1-channel 4. Support for S/PDIF In/Out 5. Support for CD In
LAN	1. 1 x Realtek 8111C chip (10/100/1000 Mbit)
Expansion Slots	1. 1 x PCI Express x16 slot, running at x16 (The PCI Express x16 slot conforms to PCI Express 2.0 standard.) 2. 4 x PCI Express x1 slots 3. 2 x PCI slots
Storage Interface	South Bridge: 1. 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices JMicron 368 chip: 1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices iTE IT8718 chip: 1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	1. Integrated in the South Bridge 2. Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1. 1 x 24-pin ATX main power connector 2. 1 x 4-pin ATX 12V power connector 3. 1 x floppy disk drive connector 4. 1 x IDE connector 5. 6 x SATA 3Gb/s connectors 6. 1 x CPU fan header 7. 2 x system fan headers 8. 1 x power fan header 9. 1 x front panel header 10. 1 x front panel audio header 11. 1 x CD In connector 12. 1 x S/PDIF In header 13. 1 x S/PDIF Out header 14. 2 x USB 2.0/1.1 headers 15. 1 x parallel port header 16. 1 x serial port header 17. 1 x power LED header 18. 1 x chassis intrusion header
Back Panel Connectors	1. 1 x PS/2 keyboard port 2. 1 x PS/2 mouse port 3. 1 x coaxial S/PDIF Out connector 4. 8 x USB 2.0/1.1 ports 5. 1 x RJ-45 ports 6. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller	1. iTE IT8718 chip
H/W Monitoring	1. System voltage detection 2. CPU/System temperature detection 3. CPU/System/Power fan speed detection 4. CPU overheating warning 5. CPU/System/Power fan fail warning 6. CPU/System fan speed control
BIOS	1. 2 x 8 Mbit flash 2. Use of licensed AWARD BIOS 3. Support for DualBIOS™ 4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	1. Support for @BIOS 2. Support for Q-Flash 3. Support for Virtual Dual BIOS 4. Support for Download Center 5. Support for Xpress Install 6. Support for Xpress Recovery2 7. Support for EasyTune 8. Support for Dynamic Energy Saver Advanced 9. Support for Time Repair 10. Support for Q-Share
Bundle Software	1. Norton Internet Security (OEM version)
Operating System	1. Support for Microsoft^® Windows Vista/XP
Form Factor	1. ATX Form Factor; 30.5cm x 21.0cm
Remark	1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. 2. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website

Gigabyte GA-EP43-US3L

Giá: 1,655,100 VND

Gigabyte GA-EP43-UD3L

Specifications

CPU	1. Support for an Intel^® Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel^® Core™ 2 Duo processor/ Intel^® Pentium^® Dual-Core processor/Intel^® Celeron^® processor in the LGA 775 package (Go to GIGABYTE's website for the latest CPU support list.) 2. L2 cache varies with CPU
Front Side Bus	1. 1600(O.C.)/1333/1066/800 MHz FSB
Chipset	1. North Bridge: Intel^® P43 Express Chipset 2. South Bridge: Intel^® ICH10
Memory	1. 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory 2. Dual channel memory architecture 3. Support for DDR2 1200+/1066/800/667 MHz memory modules (Go to GIGABYTE's website for the latest memory support list.)
Audio	1. Realtek ALC888 codec 2. High Definition Audio 3. 2/4/5.1/7.1-channel 4. Support for S/PDIF In/Out 5. Support for CD In
LAN	1. 1 x Realtek 8111C chip (10/100/1000 Mbit)
Expansion Slots	1. 1 x PCI Express x16 slot, running at x16 (The PCI Express x16 slot conforms to PCI Express 2.0 standard.) 2. 4 x PCI Express x1 slots 3. 2 x PCI slots
Storage Interface	South Bridge: 1. 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices JMicron 368 chip: 1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices iTE IT8718 chip: 1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	1. Integrated in the South Bridge 2. Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1. 1 x 24-pin ATX main power connector 2. 1 x 4-pin ATX 12V power connector 3. 1 x floppy disk drive connector 4. 1 x IDE connector 5. 6 x SATA 3Gb/s connectors 6. 1 x CPU fan header 7. 2 x system fan headers 8. 1 x power fan header 9. 1 x front panel header 10. 1 x front panel audio header 11. 1 x CD In connector 12. 1 x S/PDIF In header 13. 1 x S/PDIF Out header 14. 2 x USB 2.0/1.1 headers 15. 1 x parallel port header 16. 1 x serial port header 17. 1 x power LED header 18. 1 x chassis intrusion header
Back Panel Connectors	1. 1 x PS/2 keyboard port 2. 1 x PS/2 mouse port 3. 1 x coaxial S/PDIF Out connector 4. 1 x optical S/PDIF Out connector 5. 8 x USB 2.0/1.1 ports 6. 1 x RJ-45 ports 7. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller	1. iTE IT8718 chip
H/W Monitoring	1. System voltage detection 2. CPU/System temperature detection 3. CPU/System/Power fan speed detection 4. CPU overheating warning 5. CPU/System/Power fan fail warning 6. CPU/System fan speed control
BIOS	1. 2 x 8 Mbit flash 2. Use of licensed AWARD BIOS 3. Support for DualBIOS™ 4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	1. Support for @BIOS 2. Support for Q-Flash 3. Support for Virtual Dual BIOS 4. Support for Download Center 5. Support for Xpress Install 6. Support for Xpress Recovery2 7. Support for EasyTune 8. Support for Dynamic Energy Saver Advanced 9. Support for Time Repair 10. Support for Q-Share
Bundle Software	1. Norton Internet Security (OEM version)
Operating System	1. Support for Microsoft^® Windows Vista/XP
Form Factor	1. ATX Form Factor; 30.5cm x 21.0cm
Remark	1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. 2. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website

Gigabyte GA-EP43-UD3L

Giá: 1,728,660 VND

GIGABYTE GA-G41M-ES2L

Specifications

CPU	1. Support for an Intel^® Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel^® Core™ 2 Duo processor/ Intel^® Pentium^®processor Extreme Edition/Intel^® Pentium^®D processor/Intel^® Pentium^®4 processor Extreme Edition/Intel^® Pentium^®4 processor/Intel^® Celeron^®processor in the LGA 775 package 2. L2 cache varies with CPU
Front Side Bus	1. 1333/1066/800 MHz FSB
Chipset	1. North Bridge: Intel^® G41 Chipset 2. South Bridge: Intel^® ICH7
Memory	1. 2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory (Note 1) 2. Dual channel memory architecture 3. Support for DDR2 800/667 MHz memory modules Because of chipset limitations * To avoid the system being unable to start or the memory being incorrectly detected, if only one memory module is to be installed, we suggest that you install it on the DDR2_1 or DDR2_3 socket; to install two memory modules, we suggest that you install them on the DDR2_1 and DDR2_3 sockets. * Do not populate both DIMM sockets of the same channel (e.g. DDR and DDR2), or populate 4 DIMM sockets with double-sided memory modules to prevent system's failure to start or incorrect detection of memory modules. Please refer to the user manual for the memory configurations table.
Onboard Graphics	1. Integrated in the North Bridge
Audio	1. Realtek ALC888B codec 2. High Definition Audio 3. 2/4/5.1/7.1-channel (Note 2) 4. Support for S/PDIF In/Out 5. Support for CD In
LAN	1. Realtek 8111DL chip (10/100/1000 Mbit)]
Expansion Slots	1. 1 x PCI Express x16 slot, running at x 16 2. 1 x PCI Express x1 slot 3. 2 x PCI slots
Storage Interface	South Bridge: 1. 1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices 2. 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices iTE IT8718 chip: 1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	1. Integrated in the South Bridge 2. Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1. 1 x 24-pin ATX main power connector 2. 1 x 4-pin ATX 12V power connector 3. 1 x floppy disk drive connector 4. 1 x IDE connector 5. 4 x SATA 3Gb/s connectors 6. 1 x CPU fan header 7. 1 x system fan header 8. 1 x front panel header 9. 1 x front panel audio header 10. 1 x CD In connector 11. 1 x S/PDIF In /Out header 12. 2 x USB 2.0/1.1 headers 13. 1 x serial port header 14. 1 x power LED header 15. 1 x chassis intrusion header
Back Panel Connectors	1. 1 x PS/2 keyboard port 2. 1 x PS/2 mouse port 3. 1 x parallel port 4. 1 x serial port 5. 1 x D-Sub port 6. 4 x USB 2.0/1.1 ports 7. 1 x RJ-45 port 8. 3 x audio jacks (Line In/Line out/Microphone)
I/O Controller	1. iTE IT8718 chip
H/W Monitoring	1. System voltage detection 2. CPU temperature detection 3. CPU/System fan speed detection 4. CPU overheating warning 5. CPU/System fan fail warning 6. CPU fan speed control (Note 3)
BIOS	1. 2 x 8 Mbit flash 2. Use of licensed AWARD BIOS 3. Support for DualBIOS™ 4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	1. Support for @BIOS 2. Support for Q-Flash 3. Support for Virtual Dual BIOS 4. Support for Download Center 5. Support for Xpress Install 6. Support for Xpress Recovery2 7. Support for EasyTune (Note 4) 8. Support for Easy Energy Saver (Note 5) 9. Support for Time Repair 10. Support for Q-Share
Bundle Software	1. Norton Internet Security (OEM version)
Operating System	1. Support for Microsoft^® Windows Vista/XP
Form Factor	1. Micro ATX Form Factor; 24.4cm x 19.4cm
Remark	1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. 2. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.
Note	(Note 1) Due to Windows Vista/XP 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB. (Note 2) To configure 7.1-channel audio, you need connect with the port of HD Audio standard via front panel and enable the multi-channel audio feature through the audio driver. (Note 3) Whether the CPU fan speed control function is supported will depend on the CPU you install. (Note 4) Available functions in EasyTune may differ by motherboard model. (Note 5) Due to the hardware limitation, you must install the Intel® CoreTM 2 Extreme/ CoreTM 2 Quad/ CoreTM 2 Duo/ Pentium Dual-Core/ Celeron Dual-Core/ Celeron 400 Series CPU to enable support for Easy Energy Saver.

GIGABYTE GA-G41M-ES2L

Giá: 1,232,130 VND

GA-EP41-UD3L

Specifications

CPU	1. Support for an Intel^® Core™ 2 Extreme processor/ Intel^® Core™ 2 Quad processor/Intel^® Core™ 2 Duo processor/ Intel^® Pentium^® processor/Intel^® Celeron^®processor in the LGA775 package (Go to GIGABYTE's website for the latest CPU support list.) 2. L2 cache varies with CPU
Front Side Bus	1. 1333/1066/800 MHz FSB
Chipset	1. North Bridge: Intel^® G41 Express Chipset 2. South Bridge: Intel^® ICH7
Memory	1. 4 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory 2. Dual channel memory architecture 3. Support for DDR2 800/667 MHz memory modules (Go to GIGABYTE's website for the latest memory support list.)
Audio	1. Realtek ALC888 codec 2. High Definition Audio 3. 2/4/5.1/7.1-channel 4. Support for S/PDIF In/Out 5. Support for CD In
LAN	1. RTL8111D chip (10/100/1000 Mbit)
Expansion Slots	1. 1 x PCI Express x16 slot, running at x16 2. 3 x PCI Express x1 slots 3. 3 x PCI slots
Storage Interface	South Bridge: 1. 1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices 2. 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices iTE IT8718 chip: 1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	1. Integrated in the South Bridge 2. Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors	1. 1 x 24-pin ATX main power connector 2. 1 x 4-pin ATX 12V power connector 3. 1 x floppy disk drive connector 4. 1 x IDE connector 5. 4 x SATA 3Gb/s connectors 6. 1 x CPU fan header 7. 2 x system fan headers 8. 1 x power fan header 9. 1 x front panel header 10. 1 x front panel audio header 11. 1 x CD In connector 12. 1 x S/PDIF In header 13. 1 x S/PDIF Out header 14. 2 x USB 2.0/1.1 headers 15. 1 x power LED header 16. 1 x chassis intrusion header 17. 1 x clearing CMOS jumper
Back Panel Connectors	1. 1 x PS/2 keyboard port 2. 1 x PS/2 mouse port 3. 1 x parallel port 4. 1 x coaxial S/PDIF Out connector 5. 1 x optical S/PDIF Out connector 6. 1 x serial port 7. 4 x USB 2.0/1.1 ports 8. 1 x RJ-45 port 9. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/ Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller	1. iTE IT8718 chip
H/W Monitoring	1. System voltage detection 2. CPU/System temperature detection 3. CPU/System/Power fan speed detection 4. CPU overheating warning 5. CPU/System/Power fan fail warning 6. CPU/System fan speed control
BIOS	1. 2 x 8 Mbit flash 2. Use of licensed AWARD BIOS 3. Support for DualBIOS™ 4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features	1. Support for @BIOS 2. Support for Q-Flash 3. Support for Virtual Dual BIOS 4. Support for Download Center 5. Support for Xpress Install 6. Support for Xpress Recovery2 7. Support for EasyTune 8. Support for Dynamic Energy Saver Advanced 9. Support for Time Repair 10. Support for Q-Share
Bundle Software	1. Norton Internet Security (OEM version)
Operating System	1. Support for Microsoft^® Windows^® Vista/XP
Form Factor	1. ATX Form Factor; 30.5cm x 21.0cm
Remark	1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. 2. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website

GA-EP41-UD3L

Giá: 1,397,640 VND

SONY VAIO NW120J

Giá: 18,347,800 VND
